Found an old Commodore Amiga A500 with Power supply only.

After this thing arrived at home,

i opened the chassis.

Sadly i must broken the seals :( and surprise,

a lot of retro dust inside.

Some PCB cleaning done.

Connected all together (Amiga, Composite and Power).

Greetings from Kickstart 1.3 :-)

Now my next things i want to build are....

- Arduino Floppy Disk reader/writer -

Amiga disk ADF image Reader/Writer for PC

with Arduino controlled PC Floppy drive

- File Transfer PC<>Amiga -

Transfer files and ADF images from Linux NAS<>Amiga

- RGB to Scart-AV cable -

- Arduino PS/2 mouse converter -

PS/2 Mouse to Amiga converter

with Joystick mode

- Slow/Ranger/Trapdoor RAM -

Expansion RAM with 30Pin SIMM modules

- IDE/Compact Flash Interface -

IDE Interface based on A500ide

- Kickstart Update / Flash -

Flashable Kickrom

- Mouse Replacement (w/o Arduino) -

Optical mouse to Amiga Conversion

UPDATE JAN 2018

- Vortex ATonce Rev.2 -

AT 286 Emulator/Bridge Board

UPDATE JAN 2021

- Terriblefire 530 Accelerator -

Homebrew accelerator card with 68040 cpu, 2MB fast ram and IDE connector

Downloads:

- Amiga A500 Schematic -
